ElectriCinema 235 - In Ceiling Screen with Side Masking

Designed to work with projectors that use anamorphic lens technology

SIZES 84" - 150" DIAGONAL

With the ElectriCinema 235 you can have the best of both worlds: 2.35:1 Cinemascope for DVDs, and, by using the motorised side masking system, reshape the screen to 16:9 HDTV for widescreen TV broadcasts.

Supplied as an integrated in-ceiling solution, with a painted underside and ceiling edge trims for a single trade install.

DESCRIPTION

In-ceiling screen system with side masking for dual format Cinemascope to HDTV formats

• HEADBOX

  MDF constructions with fully painted white underside & ceiling edge covers for easy install

• SIZES

  84” to 150” Diagonally, Custom Sizes & Formats available upon request

• SURFACE

  Side tensioned Unity White black backed PVC - Gain 1.0

• ROLLER DIAMETER

  80mm Heavy Duty

• BORDER

  50mm Sides & 100mm Bottom with 500mm adjustable top black leader

• TOP LEADER

  For sizes 100” and under the maximum total top black leader available is 500mm, for screen sizes over 100”
  The maximum top black leader available is 600mm

BENEFITS INCLUDE:

• ORIGINAL MOVIE ASPECT RATIO 2.35:1

• INTEGRATED SIDE MASKING FOR 16:9

• ONE-PIECE IN-CEILING DESIGN

• FLUSH SITTING MASKING, WITH NO SHADOW-LINE

• INDUSTRY LEADING CONNECT CONTROL SYSTEM

• ALLOWS IR CONTROL OR CONTACT CLOSE FOR INTEGRATION WITH CONTROL SYSTEMS

• LINKS WITH OTHER CONNECT DEVICES, SUCH AS PROJECTOR LIFTS OR ROLLER BLIND SYSTEMS

• SIDE TENSIONED SURFACE FOR THE BEST POSSIBLE LAYFLAT
